What You Will Learn

This guide will explain what credentials are and how you can manage them inside the Workflow Executor app.

1. What are Credentials?

Credentials are login information used to authorise the user to use external tools via the app. For example using a username and password to get access to your profile information managed by a tool.

Each Command can define which authentication type it supports and is able to request a Credential from the user. Authentication types can be custom defined by the command or use one of the default available authentication types:

Bearer Token

Uses a token issued by the external tool

Rest Basic

Uses username and password for BASIC authentication

Rest Token

Uses a token for BASIC authentication

Rest OAuth

Used for Two-Factor authentication

Rest OpenId

Simple

Uses username and cleartext password for authentication

Url Only

No authentication required. Only needs to know which url to use.

Authentication can require additional information, which are defined by an authentication type. The most common are:

Endpoint

The base url where a command sends its requests to.

Username

The username of the current user

Password

The password of the current user

Token

Token used for authentication.

2. Managing Your Credentials

You can access the credentials the app uses under Options > Login-Data .

Login Data Location

The following chapters will lead you through the different functionalities of the Login-Data dialog.

2.1. Create a new Credential

Normally you don’t need to create your Credentials manually as you will be asked to provide them, when executing a Command.

To create new Login-Data simply:

Login Data Dialog

To create a new set of credentials, simply click the ‚Add new Login-Data‘ button.

The resulting form will allow you to define the credentials.

Login Data Create Dialog
1 Select a connector id via the dropdown or entering the id in the textbox.
2 Select an authentication type via the combobox.
3 All needed information for the specific authtype can be inserted into the fields below.
4 Credentials can be specified to use a specific proxy. This feature is explored in more detail in the Proxy Settings Guide.
5 Hit Save to create new Credentials.
You can reload all available Connectors by hitting the button next to the drop down
Various values might be prefilled from other credentials with the same adapter id, or preset by the requesting Command.

2.2. Editing Information of a Credential

To edit credentials double-click on the desired credential row or select the row and click on the ‚pencil‘ button in the top right corner.

LognDataDialog Edit

A dialog displaying all the information saved by the credentials will appear afterwards.

Login Data Edit Dialog
1 You cannot change the authentication type of the Credentials!
2 Editing the used proxy settings is further described in more detail in the Proxy Settings Guide.
3 You can edit the information of the Credentials.
4 Hit Save to save your changes.

2.3. Selecting Default Credential

Credentials with the same Adapter id are grouped and one entry is always marked as Default. When a Command does not specify which endpoint/address or which Credential it wants to use, then it will use the Credential marked as Default.

To mark a different credential as default, simply click the checkbox inside the Default-Column.

LognDataDialog Switch
Don’t forget to save your changes by clicking on the Save changes button in the bottom right corner!

2.4. Deleting Credentials

When you don’t need a Credential anymore, just select the Credential and click the Trash button in the top right corner.

LognDataDialog Delete

3. What You Have Learned

In this guide you have learned what Credentials are, where they are used and how you can manage them. All the options of the Login-Data dialog where explored which allow creation, editing and deleting of Credentials.
